Model No | RZ-GSP-P15mm-S |
Pixel pitch (mm) | Horizontal 15.625mm Vertical 15.625mm |
Pixel types | SMD2727 |
Resolutions(dot/㎡) | 4096 |
Cabinet size(mm) | 500(W) X 1000(H) |
Cabinet resolutions(dots) | 32(W) X 64(H) |
Weight( kg/cabinet) | 7.5 |
Weight (kg/sqm) | 15 |
Cabinet thickness (cm) | 6.3 |
Installation thickness (cm) | 12.3(frame thickness is for 6cm) |
Max power consumption (W/㎡) | 450 |
Ave power consumption(W/㎡) | 135 |
Brightness (cd/㎡) | ≥6500cd |
Grey level (bit) | 14 |
Color temperature (K) | 6500-9300k |
Brightness adjustment (without hurting grey level) | 0-255 |
Viewing angle (degree) | Horizontal ≥120° vertical ≥120° |
Best viewing distance | 10-300 |
Frame rate (HZ) | 60 |
Controller | Synchronous mapping |
Driving method | Constant current,static |
Power supply voltage | 85-250 |
Lifespan | 100000 hours |
Heating dissipating | structure-enhanced,natural convection |
Strip width | 8.8 |
Strip material | aluminum 6061 |
Tranparancy | 45% |
Ip grade | Double-side IP67 |
Working temp/Storage temp | ’-35~ + 80°C / -55 ~ + 120°C |
Frame material | 2.0mm cold-rolled galvanized steel sheet |
Fireproof | quick installation Tool-free |
Maintenance speed | 10S/unit |
Maintenance method | Front side or Back side |
