Overview
Quick Details
- Place of Origin:
- Guangdong, China
- Brand Name:
- REIDZ
- Model Number:
- S-SPB-P100
- Color:
- full color
- Working voltage:
- AC85~265V
- Protection level:
- IP44
- Viewing angle:
- 120 degree
- Gray Grades:
- 4096 levels for each color
- Material:
- Velvet flame retardant fabric
- Name:
- stage decoration backdrop fabric
- Type:
- Event & Party Supplies
- Event & Party Item Type:
- Party Decoration
- Occasion:
- Wedding
The fabric led curtain is made of Velvet flame retardant cloth, it's soft, foldable, very convenient for transportation and installation. The pixel pitch can be P50mm or P100mm. This led curtain can be controlled by DMX led controller or SD card or sound activation controller,it can display animation effects. Can customize the size for the clients.It's widely used for night club, bar, disco ceiling or wall, or use on stage as backdrop.
Model No. | S-SPB-P50 | S-SPB-P100 |
Pixel pitch | P50mm | P100mm |
Pixel density per square meter | 400 pcs pixel / SQM | 100pcs pixel / SQM |
Power consumption W/SQM | 160W/ SQM | 40W / SQM |
Weight | 8kgs/m2 | 3kgs/m2 |
Pixel configuration | F5 super brightness led | |
Brightness adjustment | 4096 level | |
Viewing angle | 120 degree | |
Out of control point | <0.0002 | |
Lifespan(H) | >50000hours | |
Working temperature | Miner 10 to 40 degree | |
Humidity | 10% to 90%RH | |
Protection level | IP44 | |
Working voltage | AC85~265V | |
Control system | DMX512,3-pin XLR input/output connector,4pin data output | |
DVI | ||
Auto-run | ||
sound activation | ||
Cloth material | Velvet flame retardant fabric, fireproof material |
Product Features
1) Flexible soft features --- can be rolled/curved/hanged/piled... ;
2) Soft led screen material --- with pixel pitch 50mm / 100mm
3) Full color RGB leds --- nice video effect & dreamy graphics performance;
4) Fast set-up & take-down --- lightweight body, easy to handle, no tool needed;
5) Meticulous component---every led pixel has a plastic box protecting its feet and wires;
6) Single led pixel replacement --- easy to maintain;
7) Tin soldered wires --- stable signal and power transferring;
8)Application: as stage backdrop, wedding stage backrop, catwalker ceiling decor, nightclub, disco bar wall decor...
