| Model No | RZ-GSP-P25-50mm-D |
| Pixel pitch (mm) | Horizontal 50mm Vertical 25mm |
| Pixel types | DIP346 (1R1G1B) |
| Resolutions(dot/㎡) | 800 |
| Cabinet size(mm) | 500(W) X 1000(H) |
| Cabinet resolutions(dots) | 10(W) X 40(H) |
| Weight( kg/cabinet) | 6 |
| Weight (kg/sqm） | 12 |
| Cabinet thickness (cm) | 6.7 |
| Installation thickness (cm) | 12.7(frame thickness is for 6cm) |
| Max power consumption (W/㎡) | 300 |
| Ave power consumption(W/㎡) | 90 |
| Brightness (cd/㎡) | ≥2500cd |
| Grey level (bit) | 14 |
| Color temperature (K) | 6500-9300k |
| Brightness adjustment (without hurting grey level) | 0-255 |
| Viewing angle (degree) | Horizontal ≥110° vertical ≥70° |
| Best viewing distance | 40-800 |
| Frame rate (HZ) | 60 |
| Controller | Synchronous mapping |
| Driving method | Constant current,static |
| Power supply voltage | 85-250 |
| Lifespan | 100000 hours |
| Heating dissipating | structure-enhanced,natural convection |
| Strip width | 9.8 |
| Strip material | aluminum 6061 |
| Tranparancy | 85% |
| Ip grade | Double-side IP67 |
| Working temp/Storage temp | ’-35~ + 80°C / -55 ~ + 120°C |
| Frame material | 2.0mm cold-rolled galvanized steel sheet |
| Fireproof | quick installation Tool-free |
| Maintenance speed | 10S/unit |
| Maintenance method | Front side or Back side |
